Electronics Labs Facilities
Some Brief Details of Our Electronics Labs Facilities
Here’s a machine name, specification, and short description:
- DC regulated power supply
D.C. Power Supply—SMPS (Single O/P), 0~30 V, 0~10 A, CV/CC, with 2 LEDs.
Meters
Quantity 2
- Digital storage oscilloscope
100Mhz with 4 Channel Digital storage
Oscilloscope
Quantity 1
- Function Waveform Generator
- SMD rework Station
Hot Air Gun Part: Working Voltage 220V AC
±10% Output Power 700 W – (10%
Maximum) Temperature Range 100-450 °C
Electric Soldering Machine Part: Working
Voltage 26V AC ±10% Output Power 40W
±10% Temperature Range 200-480°C
Quantity 2
- Digital Multi-meter Benchtop
Digital Multimeter, 4½ Digits, True Rms,
Bench Top, Mains Operation, M/R,
B/Light, 1000 V Dc/Ac, 20 A Ac/Dc, 20 M Ω Res., Cap., Freq., Cont. & Diode Test, D.H., Rel, Tr. (Hfe) Test.
Quantity 2
- Drilling machine benchtop
- LCR meter with Q measurement
Hot Air Gun Part: Working L.C.R. Meter, Bench Top, Mains Oper., LC-R-D-Q Etc. Measurements With Auto Detection. 5 Digits In 3.5″ Colour Lcd Display, 10 Hz~10 Khz C.V
Quantity 1
- Digital Meter
Insulation Resistance 40 GΩ, Test Range :
Insulation Resistance 0.2M To 200 Mohm ±
3.0%+5 200M To 4 Gohm ± 5.0%+5 4G,
Accuracy : To 40 Gohm ± 10%+5, Insulation
Test: VOLTAGE1000V, 2500V (DC), Short
Circuit Current: 1.5 Ma
Quantity 1
- Universal Programmer USB
- Laser Distance Meter
Product Dimensions 105x41x24 mm
Operating Environment -10° to 50°C
Laser Diode 635 nm, P<1 mW,
Measurement Range 40 m
Quantity 1
- Coil winding Machine Programmable
Coil Diameter:100 Millimetre (mm),
Automatic
Quantity 1
- Lux Meter
